Photoneo MotionCam-3D Color Pricing & Product Details

Parallel Structured Light™ - the future of industrial machine vision

Photoneo’s unique patented technology provides high quality and high resolution 3D data even for dynamic scenes. While ToF or Active Stereo systems provide real-time stream of data, the accuracy and resolution is limited. Sequential Structured Light systems provide high quality data, but at low FPS and only when the scene is completely static.

Paradigm shift in Machine Vision opens new Frontiers

Ability to provide high-quality area snapshot 3D data in near real-time opens new frontiers for industrial automation. Robots do not need to stop to acquire data (hand eye use case) or can manipulate objects moving at random motion. Never again compromise between the ability to scan dynamic scenes and the resulting resolution and data quality.

Benefits of MotionCam-3D Color:

Scanning in & rapid motion: one frame acquisition, 40 m/s

High resolution & accuracy: 2 MP, 0.150 mm

Practical scanning range: 3 models: from 36 cm - 3 m

No 3D motion blur: 10 µs per pixel exposure time

Industry ready: IP65, PoE, Thermal calibration

Operating Modes:

Dynamic scenes /0.9 Million 3D points / @ 20 FPS / Accuracy 0.6 mm at Z=1000 mm

Static scenes / 2 Million 3D points / Accuracy 0.3 mm at Z=1000 mm
