BANNER Type 4 safety light curtain EZ-SCREEN LS SERIES Pricing & Product Details

Name: Type 4 safety light curtain EZ-SCREEN LS SERIES
Brand: BANNER
SKU: 513246
Rating: 5 (1 reviews)

5/5 (1) Write a review!

Ranked Nr. 6 of 122 Safety Scanners

FIND SUPPLIER

See all 122 Safety Scanners

Add to comparison

Type 4 safety light curtain EZ-SCREEN LS SERIES Pricing

Price indication:

FIND SUPPLIER

Type 4 safety light curtain EZ-SCREEN LS SERIES Overview

What is Type 4 safety light curtain EZ-SCREEN LS SERIES?

BANNER's EZ-SCREEN LS light curtains are a reliable and easy-to-use safety device designed for machine safeguarding in challenging manufacturing and packaging environments. With three resolutions available, ranging from 14 mm to 40 mm, and a range of up to 12 m, these light curtains provide end-to-end sensing with no blind zones. The aluminum housing and metal end caps protect each emitter and receiver against impacts, while highly visible alignment indicators and intuitive diagnostics make setup and troubleshooting a breeze.

The EZ-SCREEN LS system requires no PC software or DIP switches for quick and easy configuration. The dual scan technology ensures high immunity to EMI, RFI, ambient light, weld flash, and strobe light. The no blind zone design eliminates gaps in detection, while the system can cascade up to four systems of any length, resolution, and number of beams.

These light curtains are certified to Type 4 per IEC 61946, Category 4 PLe per EN ISO13849.1, and SIL3/SILCL3 per IEC 61508/IEC 62061, exceeding OSHA/ANSI control reliability requirements. The EZ-SCREEN LS pair model numbers come with an LS receiver, LS emitter, end-cap bracket kit, and center-mount bracket kit, making them a reliable choice for a range of manufacturing and packaging applications.

What applications is Type 4 safety light curtain EZ-SCREEN LS SERIES product best for?

BANNER's EZ-SCREEN LS Series safety light curtains are a versatile and reliable solution for machine safeguarding in a range of industrial applications. These light curtains are built to withstand the challenges commonly found in manufacturing and packaging environments, providing an intuitive and easy-to-use safety device that can help prevent accidents and injuries.

With three resolutions available (14 mm, 23 mm, and 40 mm) and a range of up to 12 m (39 ft), EZ-SCREEN LS light curtains offer flexibility in their detection capabilities, allowing them to be tailored to specific applications and environments. The emitter and receiver are protected against impact by a 3 mm thick aluminum housing and metal end caps, and feature a 5 mm recessed window to further enhance durability.

One of the key benefits of the EZ-SCREEN LS Series is their ease of use and configuration. The system requires no PC software, DIP switches, or other devices, making setup quick and straightforward. Highly visible alignment indicators and intuitive diagnostics further simplify the setup process, and can help minimize downtime by facilitating troubleshooting.

The EZ-SCREEN LS Series also benefits from dual scan technology, which makes the sensor highly immune to EMI, RFI, ambient light, weld flash, and strobe light. This robust design ensures that the sensor remains reliable and accurate even in challenging environments, helping to minimize false alarms and downtime.

The no-blind-zone design of the EZ-SCREEN LS Series provides end-to-end sensing to eliminate gaps in detection, while the ability to cascade up to four systems of any length, resolution, and number of beams allows for further customization and scalability. And with IP65/IP67 rated emitter/receiver pairs that exceed OSHA/ANSI control reliability requirements and are certified to Type 4 per IEC 61946, Category 4 PLe per EN ISO13849.1, and SIL3/SILCL3 per IEC 61508/IEC 62061, you can have confidence in the safety and reliability of these light curtains.
