intel RealSense™ Depth Camera D455 Specifications

4.5/5 (10) Write a review!

Ranked Nr. 6 of 93 3D Vision Systems

FIND SUPPLIER

See all 93 3D Vision Systems

The Intel® RealSense™ Depth Camera D455 is the latest addition to the D400 series, offering twice the range and improved performance. With a distance of 95 mm between depth sensors, the D455 achieves depth error of less than 2% at 4 meters. The integration of an IMU allows for enhanced environmental awareness in robotic and drone applications, refining depth awareness during camera movement.

The D455 provides more accuracy and flexibility for various use cases. Its longer range makes it ideal for collision avoidance in fast-moving autonomous robots, ensuring safer operation in dynamic environments. The tightly integrated RGB and depth streams with a global shutter on the RGB sensor improve the correlation between color and depth information, resulting in better quality scanning. For touch-free displays in public spaces, the longer range of the D455 enables reliable gesture control and interaction from a greater distance. Additionally, multiple D455 cameras can be easily set up together for volumetric content creation, offering real-time scene capture at up to 90 frames per second, both indoors and outdoors.

Choose your model:
RealSense™ Depth Camera D405 Color | Monochrome | Near-infrared | Working distance 10000mm RealSense™ Depth Camera D415 Color | Monochrome | Near-infrared | Working distance 10000mm RealSense™ Depth Camera D435 Color | Monochrome | Near-infrared | Working distance 10000mm RealSense™ Depth Camera D435i Color | Monochrome | Near-infrared | Working distance 10000mm RealSense™ Depth Camera D435f Near-infrared | Working distance 10000mm RealSense™ Depth Camera D455 Color | Monochrome | Near-infrared
Industry
  • Education
  • Automotive
  • Food and Beverage
  • Packaging
  • Healthcare
  • Electronics
  • Aerospace and Defense
  • Energy and Utilities
Application
  • AR/VR Integration
  • Object Recognition & Control
  • Precise Measurement & Guiding
  • Quality Control & Inspection
  • Robotics & Automation
  • Security & Surveillance
Image Type
  • Color
  • Hyperspectral
  • Monochrome
  • Multispectral
  • MWIR
  • Near-infrared
  • SWIR

RealSense™ Depth Camera D455 Alternatives

See all 159 3D Vision Systems
intel RealSense™ Depth Camera D415
Color | Monochrome | Near-infrared | Working distance 10000mm

4.5/5 (10)

The Intel® RealSense™ Depth Camera D415 stands out for its standard field of view, making it well-suited for high-accuracy applications like 3D scanning. With a rolling shutter on the depth sensor, it offers the highest depth quality per degree, enabling precise measurements for smaller objects or when more accuracy is required. The D415 is lightweight, powerful, and cost-effective, making it an ideal choice for development and productization of new sensing solutions and devices that can better understand and interact with their surroundings.This camera is part of the Intel® RealSense™ D400 series, which includes a complete suite of solutions for simple integration. It combines Intel's latest depth-sensing hardware and software into easy-to-integrate products, including vision processors, turnkey modules, cameras, SDKs, and computer vision libraries. As a result, developers, makers, and innovators can easily bring depth-sensing vision to their devices, fostering a new generation of intelligent vision-equipped solutions.In industrial automation, the D415's high depth quality and precise measurement capabilities make it a valuable tool for various applications. Its ability to accurately sense and understand the environment can enhance robot guidance, object detection, and inspection tasks. Furthermore, its small form factor and customizable software allow for easy integration into existing systems, making it a versatile option for a wide range of industrial use cases. Additionally, its compatibility with Intel's vision processors and SDKs offers the potential for advanced real-time processing and data analytics in industrial environments.
Stereolabs ZED Mini
Color | Monochrome

3.2/5 (2)

The Stereolabs ZED Mini is a state-of-the-art camera that merges virtual and augmented reality seamlessly. With advanced depth sensing technology, it captures high-resolution stereo video, delivering a genuine sense of presence in 3D for mixed-reality experiences. The camera's inside-out tracking system enables natural movement through space without requiring external sensors, allowing users to interact with virtual objects in an intuitive manner.Notably, the ZED Mini offers dynamic space mapping, integrating virtual elements seamlessly into the real world with realistic lighting, shadows, and occlusions. Its low latency stereo pass-through optimizes viewing in VR headsets, enhancing the immersion in augmented environments. The camera's unique specifications make it an excellent option for industrial automation, as it can withstand extreme temperatures. Additionally, its compatibility with specialized software systems enables the perception of people and objects in space, enabling unprecedented levels of interaction and realism in augmented reality. Users can even create multi-user AR experiences, combining social interaction with immersive VR, and capture external viewpoints using a spectator ZED camera for an enhanced experience.
intel RealSense™ Depth Camera D435i
Color | Monochrome | Near-infrared | Working distance 10000mm

4.5/5 (10)

The Intel® RealSense™ depth camera D435i combines robust depth sensing with an inertial measurement unit (IMU). The addition of an IMU allows the camera to refine its depth awareness during movement, enabling rudimentary SLAM and tracking applications for better point-cloud alignment. It also enhances environmental awareness for robotics, drones, and handheld scanning systems. The IMU data is time-stamped to align with the high-quality depth data, making it valuable for applications like virtual/augmented reality and drones.The D435i integrates an IMU into a small form factor with an Intel module and vision processor, making it a complete and powerful package for development and productization. Its wide field of view and global shutter sensor make it ideal for robotic navigation and object recognition applications. The camera's wider field of view reduces blind spots, and the global shutter sensors offer excellent low-light sensitivity for navigation in dark environments.As part of the Intel® RealSense™ D400 series, the D435i offers simple integration and is perfect for developers, makers, and innovators looking to incorporate depth sensing into their intelligent vision-equipped solutions. It brings forth a new generation of devices with advanced depth sensing capabilities, driving innovation across various industries.
intel RealSense™ Depth Camera D435
Color | Monochrome | Near-infrared | Working distance 10000mm

4.5/5 (10)

The Intel® RealSense™ Depth Camera D435 boasts the widest field of view among Intel cameras, making it suitable for fast-moving applications. As a stereo solution, it delivers high-quality depth data, ideal for robotics and augmented/virtual reality applications where capturing a broad scene is crucial. With a range of up to 10 meters, its small form factor allows easy integration into various solutions, complete with Intel RealSense SDK 2.0 and cross-platform support.This camera combines an Intel module and vision processor into a compact form factor, offering a powerful and customizable depth camera solution for development and rapid product creation. Its unique combination of a wide field of view and global shutter sensor makes it ideal for low-light environments, enabling applications like robotic navigation and object recognition. As part of the Intel® RealSense™ D400 series, the D435 provides simple out-of-the-box integration for developers, makers, and innovators looking to incorporate depth sensing into their intelligent vision-equipped devices.
intel RealSense™ Depth Camera D405
Color | Monochrome | Near-infrared | Working distance 10000mm

4.5/5 (10)

The Intel® RealSense™ Depth Camera D405 is a short-range stereo camera offering sub-millimeter accuracy, making it ideal for close-range computer vision applications. Its standout feature includes the use of an image signal processor (ISP) to enhance RGB data from the depth sensor, ensuring matched RGB and depth data for improved imaging capabilities.Operating within a range of 7 cm to 50 cm, the D405 provides sub-millimeter accuracy with a minimum object detection of 0.1 mm at 7 cm. Despite its high precision, the camera maintains a small and lightweight design, measuring only 42 mm × 42 mm × 23 mm and weighing 60 g, making it compact and portable.The D405 is well-suited for a variety of industrial automation applications. In manufacturing facilities, it enables defect detection with remarkable accuracy of 0.1 mm, facilitating automated inspections and precise pick-and-place operations for small objects at close range. Additionally, the camera finds application in robotics with gripping capabilities, assembly line inspections, and even wound management in healthcare settings, providing accurate 3D measurements without the need for physical contact. Its sub-millimeter accuracy opens up a new world of use cases requiring precise close-range depth sensing.
Framos D455e Starter Kit
No reviews yet.
The starter kit of the D455e includes the camera itself, a M12 to RJ45 ethernet cable and a M8 power cable with wall plug. It comes fully equipped to start and test the camera quickly.The FRAMOS Industrial Depth Camera D455e is built with Intel® RealSense™ technology. The depth camera has industrial M12 ethernet and M8 power connectors and features a wide field of view for depth and RGB sensors. Its water- and dust resistant housing is optimized for industrial environments. The FRAMOS Industrial Depth Camera D455e is ideal for OEMs and integrators who need 3D as well as 2D vision in their products and applications. The global shutter sensors allow for applications with fast motion. The Intel® RealSenseTM D450 depth module used in this camera extends the distance between the depth sensors to 95 mm which improves the depth (Z) error* to less than 2% at 4 m.To improve the RGB image and the correspondence between the depth and RGB images, the RGB sensor includes a global shutter and is matched to the depth FOV with both having an 86° field of view.The FRAMOS Industrial Depth Camera D455e is compatible with the Cross-platform SDK for Intel® RealSense™ devices, enabling multiple programming languages, wrappers, sample code and tools.
intel RealSense™ Depth Camera D435f
Near-infrared | Working distance 10000mm

4.5/5 (10)

The Intel® RealSense™ Depth Camera D435f is designed to meet the demands of the growing market for autonomous mobile robots. Its standout feature is the utilization of an IR pass filter, which enhances depth noise quality and extends performance range in various robotic environments. The camera's improved depth quality in scenes with repetitive patterns and mitigation of visible reflections make it suitable for both indoor and outdoor applications.With the incorporation of a 750nm near-infrared filter during Intel's production process, the D435f offers easy out-of-the-box integration. It effectively resolves false depth perception caused by repetitive vertical patterns, such as poles in airports, vertical blinds, ceiling pipes, floor drains, and small floor tiles.The D435f is a valuable addition to the D400 family, widely utilized in a diverse range of robotic use cases. Its enhanced depth quality and capabilities make it an excellent choice for robotics applications in real-world scenarios, contributing to improved performance and efficiency in autonomous mobile robot systems.
Framos Industrial Depth Camera D415e Starter Kit
Working distance 300-10 mm
No reviews yet.
The starter kit of the D415e includes the camera itself, a M12 to RJ45 ethernet cable and a M8 power cable with wall plug. It comes fully equipped to start and test the camera quickly.The FRAMOS Industrial Depth Camera D415e is built with Intel® RealSense™ technology. The depth camera has industrial M12 ethernet and M8 power connectors and features a field of view of approx. 72° (diagonal) for depth and RGB sensors. Its water- and dust resistant housing is optimized for industrial environments. The D415e is ideal for OEMs and integrators who need 3D as well as 2D vision in their products and applications. The wider baseline of the two rolling shutter IR imagers, compared to the D435e, provides higher depth accuracy for applications that require high precision. The D415e is compatible with the Cross-platform SDK for Intel® RealSense™ devices, enabling multiple programming languages, wrappers, sample code and tools.
Basler ToF640
Monochrome
No reviews yet.
The Basler ToF640 offers both 2D and 3D imaging at 15 frames per second with VGA resolution and a working range of 0 to 13 meters. Notably, its accuracy of +/- 1 centimeter at distances up to 5.8 meters ensures precise measurements. This time-of-flight camera employs infrared LEDs to emit light pulses that are reflected off the target and registered by the sensor's pixels, enabling accurate distance calculation.The camera provides calibrated range images in various formats, including Mono16, RGB8, and Coord3D_ABC32f. Its automatic exposure control and specialized Pylon software simplify configuration and image viewing. The Basler ToF640's versatility is evident in applications such as shape and volume measurement, carton stacking, object location, and autonomous vehicle crash avoidance. Moreover, its compatibility with different image formats and confidence map enhances data integrity, making it a valuable tool in industrial automation.Additionally, the camera's ability to generate a 3D point cloud as a PLY polygon file adds to its unique features. This special output enables precise spatial visualization, contributing to its suitability for applications requiring accurate object detection, manipulation, and assessment. Furthermore, the Basler ToF640's integration into autonomous vehicle systems showcases its potential in enhancing safety measures through crash avoidance technology.
Vzense Technology DCAM550-P
Monochrome | Working distance 350-6000 mm
No reviews yet.
Industrial ToF depth camera Ethernet and RS485 Interface Support POE+/DC as power supply KEY FEATURESIR and depth output simultaneouslyVzense ToF products can output 12 bit depth images and black-and-white images at the same time. The two images are completely aligned in time and space.Passive trigger modeDCAM550 series can work in the passive trigger mode, which means DCAM550 series is always in the slave standby mode, waiting to receive the trigger signal to start acquiring one frame of data, subsequently, entering the slave standby mode again. OUTDOOR STRONG LIGHT EFFECT DCAM550 series works perfectly under extreme sunlightTest condition: 82k lux
Vzense Technology DCAM550-U
Monochrome | Working distance 350-6000 mm
No reviews yet.
Industrial ToF depth camera USB 2.0 & RS485 Interface KEY FEATURES IR and depth output simultaneouslyVzense ToF products can output 12 bit depth images and black-and-white images at the same time. The two images are completely aligned in time and space. Passive trigger modeDCAM550 series can work in the passive trigger mode, which means DCAM550 series is always in the slave standby mode, waiting to receive the trigger signal to start acquiring one frame of data, subsequently, entering the slave standby mode again. OUTDOOR STRONG LIGHT EFFECT DCAM550 series works perfectly under extreme sunlightTest condition: 82k lux
See all RealSense™ Depth Camera D455 Alternatives
