Top 10 ALSS- STANDARD LINEAR FLOOR AXES Alternatives

  • igus drylin® ZLW toothed belt axes
1
igus drylin® ZLW toothed belt axes
No reviews yet.
Max. Stroke 1000-3000 mm


The drylin® toothed belt axes in the ZLW series are suitable for many different positioning and adjustment tasks. The lubrication-free drylin® W profile guide acts as a linear guide and a toothed belt acts as a drive. The stroke is individually selectable. Thanks to the lightweight design using plastic and aluminium, drylin® ZLW toothed belt axes have a low mass inertia, making them highly efficient. Whether as an individual system or a linear robot, the ZLW series offers the ideal solution in both confined spaces and applications that require a high level of torque support . All drylin® ZLW toothed belt axes can be ordered ready for connection and configured with drylin® E stepper and DC motors.

Special properties

  • End supports with grooved ball bearing
  • Lubrication-free linear guide system with polymer plain bearings
  • Various carriage lengths
  • Hard-anodised aluminium profile
  • Polyurethane or neoprene toothed belts


When to use it?

  • Quick positioning of small loads
  • Quiet running
  • Slim structure
  • Underwater application with UW belt
  • Cost-effective solution as basic version
  • Continuous operation

When not to use it?

  • When high loads need to travel at dynamic forces
  • When positioning accuracy < 0.1 mm is necessary
