Nord Modules PL-EU-Omron MD Pricing & Product Details

The PL-EU-Omron MD is a highly efficient top module designed for compatibility with the Omron MD-650 and MD-900 autonomous mobile robots. This module is engineered to enhance internal logistics by automating the transportation of EU-sized pallets. With dimensions of 1187 x 2×162 x 145 mm, it is capable of handling payloads of up to 575 kg for the MD-650 model and 825 kg for the MD-900 model. The lifting speed is uniform at 4 seconds for both lifting and lowering operations, ensuring swift and stable transport.

One of the standout features of the PL-EU-Omron MD is its robust design, which includes an industrial actuator with a ball screw spindle, a servo motor, and a dynamic brake. The scissor lift design with cam followers and bearings in all moving joints allows it to handle uneven loads effectively. Additionally, the module can be easily mounted on the AMR by removing 4x4 screws to access the mounting points, facilitating quick and secure installation.

The applications of the PL-EU-Omron MD are particularly suited for manufacturing plants, warehouses, and logistics centers where the efficient and stable transport of EU-sized pallets is crucial. It enables the MD-650 and MD-900 robots to autonomously lift and lower pallets from the P&D Cantilever Stand and Pallet Rack MD. The module's longevity, with a minimum of 600,000 lift cycles at maximum payload, coupled with its data collection capabilities, including total lift count and error codes, ensures reliable performance and continuous monitoring, enhancing productivity and operational efficiency.
