YAMAHA GX10 Pricing & Product Details
Ranked Nr. 10 of 33 Linear Motion Systems
GX10 Pricing
Choose your model
GX05
Max. Stroke 800mm | Vertical Payload 8kg | Horizontal Payload 13kg
GX05L
Max. Stroke 800mm | Vertical Payload 12kg | Horizontal Payload 32kg
GX07
Max. Stroke 1100mm | Vertical Payload 16kg | Horizontal Payload 85kg
GX10
Max. Stroke 1250mm | Vertical Payload 30kg | Horizontal Payload 100kg
GX12
Max. Stroke 1250mm | Vertical Payload 45kg | Horizontal Payload 115kg
GX16
Max. Stroke 1450mm | Vertical Payload 55kg | Horizontal Payload 130kg
GX20
Max. Stroke 1450mm | Vertical Payload 65kg | Horizontal Payload 160kg
Price indication:
GX10 Overview
What is GX10?
Yamaha's GX10 series is a linear motor stage that comes with ground ball screws as a standard feature. All models comply with JIS Standard accuracy class C5, ensuring high precision and accuracy in positioning. The GX10 series has a positioning accuracy repeatability of ±5µm, which makes it suitable for applications that require high-precision positioning.
The GX10 series has a stroke range of 100 mm to 1250 mm, which makes it suitable for various applications. The compact design of the GX10 series makes it an ideal choice for applications where space is limited. The linear motor stage is capable of handling loads up to 70 kg and can achieve maximum speeds of up to 1000 mm/s.
The GX10 series is commonly used in applications that require high-precision and high-speed positioning, such as semiconductor manufacturing, inspection equipment, and laser processing. Its high-speed capabilities make it a great choice for applications that require fast and precise movements, while its precision and accuracy make it suitable for applications that require tight tolerances.
What applications is GX10 product best for?
The Yamaha GX10 linear motor stage is suitable for a wide range of precision applications that require high accuracy and repeatability, such as semiconductor manufacturing, optical equipment, medical devices, and precision measurement equipment. Its ground ball screws and compliance with JIS Standard accuracy class C5 ensure accurate and precise movement over its stroke range of 100 mm to 1250 mm.
What are the specifications of GX10?
| Max. Stroke | 1250 mm |
| Horizontal Payload | 100 kg |
| Vertical Payload | 30 kg |
