Alkeria CO2K-N Pricing & Product Details
Ranked Nr. 48 of 125 2D Vision Systems
CO2K-N Pricing
Choose your model
CO2K-M
Monochrome | Frame rate 175FPS
CO2K-C
Color | Frame rate 87FPS
CO4K-M
Monochrome | Frame rate 92FPS
CO12S-M
Monochrome | Frame rate 23FPS
CO2K-N
Near-infrared | Frame rate 175FPS
Price indication:
CO2K-N Overview
What is CO2K-N?
Alkeria's CO2K-N camera is an excellent option for those applications where one USB3 interface is sufficient. The CELERA One camera series provides the same level of quality, flexibility, and performance as the CELERA cameras, but in a compact and convenient package that is suitable for a wide range of applications, including automated optical inspection, high-performance sorting systems, industrial metrology, microscopy, medical diagnostics, and machine vision.
One of the advantages of CELERA One cameras is that they can be powered directly by the USB3 bus, eliminating the need for external power adapters. This makes them a cost-effective solution while still providing top speed performance.
CELERA One cameras also offer a versatile I/O interface, which enables users to control external devices such as strobe lights and encoders. It has two input lines with direct encoder interface, two output lines, and one input/output (RS422, RS644 LVDS, LVTTL). The multipurpose I/O connector provides user I/O, line/frame triggering, and direct encoder interface.
CELERA One cameras are equipped with powerful on-board image processing capabilities, allowing users to perform on-line, user-controlled image processing. This includes 8 AOI, independent LUTs, gamma correction, white balance, brightness, contrast, sharpness, saturation, and hue. The control sequencing mechanism can apply up to 64 different video settings to a chain of subsequent frames.
For developers, an easy-to-use set of software API is available that supports all major programming languages, such as Python, C#, VB, and C++ in Visual Studio or QT environment. Alkeria's Software Development Kit provided with CELERA One cameras is fully compatible with Cognex VisionPro, MVTech Halcon, NI LabView, and other major machine vision software for industrial applications.
CELERA One comes with a standard C-mount lens adapter, and other accessories are available upon request, such as F-mount adapter, shielded I/O cable, and industrial grade USB3 cables.
What applications is CO2K-N product best for?
The Alkeria CO2K-N CELERA One camera series is suitable for a wide range of applications, including:
1. Medical Imaging: The camera's high-quality image processing capabilities make it an ideal tool for medical imaging, including endoscopy, microscopy, and diagnostic imaging.
2. Pick & Place Applications: The camera's small form factor and versatile I/O interfaces make it perfect for pick & place applications, including robotic arms, automated sorting systems, and production line monitoring.
3. 3D Scanning: The camera's powerful on-board image processing capabilities make it well-suited for 3D scanning applications, including object recognition, tracking, and measurement.
4. Custom Applications: The camera's flexibility and powerful software APIs make it an ideal solution for custom applications, including machine vision, industrial inspection, and automation. With its compact design and rugged construction, it can be easily integrated into any system.
What are the specifications of CO2K-N?
| Frame rate | 175 FPS |
| Image Type |
|
