DESTACO LONG STROKE, HIGH GRIP FORCE PARALLEL GRIPPERS FOR PICK-AND-PLACE – DPL SERIES Alternatives & Competitors

Destaco’s DPDS Series includes compact, robust parallel grippers for use in confined spaces requiring a high grip force, as well as multiple part gripping that uses manifold features to create gripper arrays and long finger gripping applications. High impact resistant with double wedge design. Finger mounting on end or bottom of jaws. Thru-body mounting and multiple mounting features simplified installation. Multiple air ports support manifold interface using O-rings. Purge/scavenge ports for harsh & clean environments. Corrosion resistance hardware option.

Designed for CNC machining applications, chip/dry particulate harsh environments, and non-synchronous jaw or fixed jaw clamp operations. These units are rugged general purpose modular grippers with multi-position sensing up to four locations. Each gripper is shielded to repel metal chips and particulates. The spring assist option maintains grip in case of air pressure loss, along with synchronous or non-synchronous jaw operation. Each unit features multiple air ports to support manifold interface using O-rings and two finger mounting surfaces are present on each jaw.

Designed for delicate part handling, low friction, low pressure applications, long finger gripping applications, and non-synchronous applications requiring independent jaw motion. The DPP Series is DESTACO’s highest precision gripper with excellent part position repeatability. Zero side play and smooth operation with shielded Dual-V roller bearing design. Spring assist closed option for increased grip force or for maintaining grip upon air loss. Multiple air port locations simplifies air line routing. Supports up to four sensing positions of jaws. Synchronous or non-synchronous jaw operation. Long life supported with shielded design. Purge/scavenge ports for clean & harsh environments

DESTACO’s DPW Series is designed for wide part gripping, gantry systems, harsh gripping environments, and long finger applications. Robust wide body gripper with DIRECTCONNECT mounting. Grip force ranges from 222N thru 800N and strokes range from 19mm thru 63.5mm. Rack and pinion design for smooth operation. Its jaws are well supported to grip large and wide parts. Multiple air ports where top ports can be manifolded. Shaft wiper seals for harsh environments. Optional non-synchronous jaw operation.

Designed for feed thru work piece applications, optical workpiece inspection via center hole, and part feed/ejection, part cleaning, and part presence capability. Multipurpose robust gripper with high repeatability. Through-hole design for 3rd party tooling, imaging, part ejectors, hoses and sensing. Spring assist option maintains grip in case of air pressure loss. Grip force range from 1474N to 4332N with repeatability of +/-0.02mm.

Designed for high particulate application environments, automotive engine block, gantry systems, and ideal for very heavy part gripping. These units are rugged, multi-purpose powerful grippers. The series includes eight sizes for small lightweight to very large/heavy part gripping. High impact resistant with double wedge design. Shielded gripper to repel metal chips and particulates. Spring assist option maintains grip in case of air pressure loss, while purge and scavenge ports assist in harsh and clean environments. Multi-position sensing for up to four locations.

Designed for assembly manufacturing cells, packaging applications, and general purpose gripping. Compact cam lever designed, general purpose gripper. Pneumatic and hydraulic operation options. Spring assist option for part retention in case of air pressure loss. Standard and extended stroke option available. Shielded design for harsh environments. Magneto-resistive and inductive sensing.

Designed for long cycle life requirements, high vibration environments, pick-and-place, and part feed applications. Multipurpose robust gripper with high repeatability. Spring assist option maintains grip in case of air pressure loss. Uses inductive or magneto resistive sensors for sensing jaw position. Grip force range from 771N to 2235N. Purge and scavenge ports for harsh and clean environments. Repeatability of +/-0.02mm.

Designed for delicate part handling applications, highly repeatable/precise gripping, and clean application environments. These precision grippers offer excellent part position repeatability, rack and pinion design for precise jaw synchronization, low friction and smooth operation with Dual-V roller bearings. Maintenance free, lubricated cylinder and drive mechanism. Zero side play and maximum jaw support with preloaded bearings and supports up to two sensing positions.

Designed for inline part pressing applications, OEM machine pick-and-place, and packaging applications. These units are widely used, robust sealed design grippers for automotive assembly. Double wedge design for high impact applications. Hardened steel bottom for part pressing applications. Inductive jaw location sensing. Grip force range from 178N [40 lbs] to 2669N [600 lbs] and stroke range from 6.4mm [0.25 in] to 50.8mm [2.00 in]
