The HT-2000 camera boasts the advanced CMV2000 CMOS sensor by AMS, providing high dynamic range and exceptional frame rate performance. At full resolution of 2048×1088, you can capture up to 338 frames per second, enabling you to capture high-quality images in rapid succession.

The camera's 10GigE RJ45 interface offers 10 times the speed of traditional GigE, with the added benefit of being GigE Vision® and GenICam™ compliant. Its sleek, compact design makes it ideal for a variety of applications, while the CAT6A connection allows for cable lengths of up to 100 meters.

With multi-camera synchronization at less than 1µs and low CPU overhead, the HT-2000 is a highly cost-effective solution for capturing high-quality images. Additionally, this camera is available in monochrome (HT-2000-M), color (HT-2000-C), and near-infrared (HT-2000-N) options, providing you with the flexibility to choose the right model for your specific needs.

Category
  • Area scan camera
Temperature range 0C – 45C
Application
  • AR/VR Integration
  • Object Recognition & Control
  • Precise Measurement & Guiding
  • Quality Control & Inspection
  • Robotics & Automation
  • Security & Surveillance
Industry
  • Education
  • Automotive
  • Food and Beverage
  • Packaging
  • Healthcare
  • Electronics
  • Aerospace and Defense
  • Energy and Utilities
Frame rate 338 FPS
Image Type
  • Color
  • Hyperspectral
  • Monochrome
  • Multispectral
  • MWIR
  • Near-infrared
  • SWIR
Resolution 2.2 MP

HT-2000 Alternatives

See all 324 2D Vision Systems
Emergent Vision Technologies HR-2000
Color | Monochrome | Near-infrared | Frame rate 338FPS
No reviews yet.
The HR-2000 camera from Emergent Vision Technologies stands as a high-performance imaging solution, leveraging the advanced CMV2000 CMOS sensor by AMS. This sensor offers exceptional image quality with high dynamic range and rapid frame rate performance, capable of capturing up to 338 frames per second at full resolution (2048x1088). This speed makes it an excellent choice for applications demanding high-speed image capture.A standout feature of the HR-2000 camera is its multi-camera synchronization capability, guaranteeing precision of less than 1μs. This synchronization ensures accurate and reliable image capture across all cameras. With low CPU overhead and an attractive price-performance ratio, it serves as a cost-effective solution for various imaging tasks.The HR-2000 camera's high-speed 10GigE SFP+ interface, 10 times faster than traditional GigE, is both GigE Vision® and GenICam™ compliant. Moreover, its support for fiber cable lengths ranging from 1 meter to 10 kilometers, without requiring converters or repeaters, adds to its deployment flexibility. The optional IP67 housing makes it suitable for challenging environmental conditions, and the near-infrared option enhances its imaging capabilities in low-light conditions.
Emergent Vision Technologies HR-5000-S
Color | Monochrome | Near-infrared | Frame rate 163FPS
No reviews yet.
The HR-5000-S by Emergent Vision Technologies is a powerful machine vision camera with a range of benefits to support various applications. With the Sony Pregius IMX250 2/3” CMOS sensor, it offers high sensitivity, high frame rate, low noise, and high picture quality, enabling you to capture even the most intricate details. At full resolution (2448×2048), you get an impressive 163 frames per second, ensuring fast and accurate results. The HR-5000-S also provides multi-camera synchronization at <1μs, low CPU overhead, excellent price-performance ratio, and fiber cable lengths from 1M to 10KM without the need for fiber converters or repeaters.Furthermore, polarized sensor options using Sony Polarsens technology are available, providing additional benefits for applications that require polarized light imaging. The HR-5000-S is compatible with high-speed 10GigE SFP+ technology, providing 10 times the speed of GigE, and is GigE Vision® and GenICam™ compliant. Additionally, an optional IP67 housing is available, providing protection against dust and water, making it suitable for use in harsh environments.Applications that can benefit from the HR-5000-S include production lines, quality inspection, immersive 3D content, goal line technology, finish line vision, referee assist, sports, broadcast, entertainment, and pharmaceutical inspection.
Emergent Vision Technologies HR-8000-S
Color | Monochrome | Frame rate 110FPS
No reviews yet.
Emergent Vision Technologies' HR-8000-S is a powerful camera that utilizes the Sony IMX255 1” sensor to deliver exceptional image quality. At full resolution (4096 x 2160), the HR-8000-S can capture 110 frames per second, making it ideal for high-speed applications that require precise and accurate image capture. Other benefits of this camera include high sensitivity, low noise, and multi-camera synchronization at <1μs, which is critical for applications that require simultaneous image capture from multiple cameras.The HR-8000-S also offers a high-speed 10GigE SFP+ interface, which is ten times faster than GigE, allowing for fast and efficient data transfer. Additionally, the camera is GigE Vision and GenICam compliant, ensuring seamless integration with a variety of systems and software.For added convenience and versatility, the HR-8000-S also comes with an optional IP67 housing, providing protection against dust and water ingress. Finally, fiber cable lengths ranging from 1M to 10KM are available without the need for fiber converters or repeaters.
Emergent Vision Technologies HR-4000
Color | Monochrome | Near-infrared | Frame rate 179FPS
No reviews yet.
The HR-4000 by Emergent Vision Technologies is a powerful camera with the CMV4000 sensor by AMS, which provides high sensitivity, dynamic range, and frame rate. At full resolution (2048 x 2048), it delivers 179 frames per second. This camera offers multi-camera synchronization at <1μs, low CPU overhead, excellent price-performance ratio, and fiber cable lengths from 1M to 10KM without the need for fiber converters or repeaters. The near-infrared option is also available for this model, providing greater flexibility in imaging applications.
Emergent Vision Technologies HR-3000-S
Color | Monochrome | Near-infrared | Frame rate 216FPS
No reviews yet.
Emergent Vision Technologies' HR-3000-S camera is designed to deliver exceptional image quality and performance. Featuring the Sony Pregius IMX252 1/1.8” sensor, the HR-3000-S offers high sensitivity, low noise, and outstanding picture quality. At full resolution (2048×1536), the camera delivers an impressive 216 frames per second.In addition to its high-speed capabilities, the HR-3000-S offers multi-camera synchronization with <1μs accuracy, low CPU overhead, and an excellent price-performance ratio. With fiber cable lengths ranging from 1M to 10KM, the HR-3000-S eliminates the need for fiber converters or repeaters.Other benefits of the HR-3000-S include its high-speed 10GigE SFP+ interface, which is ten times faster than GigE, as well as its compliance with GigE Vision® and GenICam™ standards. For added convenience, an optional IP67 housing is also available.
