Bota Systems Medusa Specifications

4.7/5 (5) Write a review!

Ranked Nr. 4 of 116 End of Arm Tools

VISIT WEBSITE

Add to comparison

The Medusa FT sensor from Bota Systems is a compact and lightweight force-torque sensor that is ideal for applications that require high sensitivity and precision. This all-in-one sensor has integrated signal processing electronics, a 6 DoF IMU, and temperature sensors, making it one of the smallest and most capable sensors in its class. The Medusa sensor is suitable for a wide range of applications, including the assembly of electronic components, rehabilitation and robotic-assisted surgery, and polishing and sanding in fine mechanics.

The Medusa sensor offers several key features and benefits:

Ultra-low noise signal: Provides high precision measurements, even in challenging environments
All-in-one design: Integrated electronics and sensors minimize the need for external components
Compact and lightweight design: Weighing only 110 grams, it is easy to integrate into a wide range of systems
Support for multiple software platforms: Includes software integration for ROS, LabVIEW, and MATLAB, making it highly compatible and easy to integrate
6 DoF IMU: Provides additional measurement capabilities and enhances the overall precision of the sensor
Direct force and torque data: Outputs data in N and Nm for accurate and immediate analysis
Embedded filtering, resolution, and sampling rate: Customizable for a wide range of applications
Power supply range of 7-48 V (5V for Serial/USB): Supports a wide range of operating conditions
Overload protection: Protects the sensor from damage in the event of excessive forces or torques
Water-resistant and dustproof: Suitable for use in harsh environments
CE compatible: Meets international safety standards

The Medusa sensor is compatible with the Meca500, and Bota Systems provides complete installation kits for easy integration. The sensor is also available with EtherCAT communication for additional capabilities.

Choose your model:

MiniONE Pro Product mass 0.06kg Medusa Product mass 0.11kg Rokubi Product mass 0.12kg MegaONE Product mass 1.386kg LaxONE Product mass 0.465kg SensONE Product mass 0.22kg PixONE Payload 250kg

Application	Palletizing Picking and placing Assembly Machine loading Welding Screwing Polishing and grinding Gluing and dispensing Inspection
Industry	Education Automotive Food and Beverage Packaging Healthcare Electronics Aerospace and Defense Energy and Utilities
Product mass	0.11 kg
Type	Collision/Torque Sensors Compensation Unit Compilance Devices Connectors Dispensers Force Torque Sensors Sanders Screwdrivers Tool Changers Vacuum Generators Welding Torches Wrist Cameras
Overload	1000 N
Temperature range	0 – 55 Celsius
Range	400 N
Sampling Rate (Max.)	800 Hz

Medusa Downloads

Meca500 Medusa mount

MEDS RENDER POSE2 Logo

MED RENDER 004 c

Medusa meca 1
