Hypersen HPS-LCF1000 Specifications

No reviews yet.
Write a review!

Ranked Nr. 143 of 93 3D Vision Systems

FIND SUPPLIER

See all 93 3D Vision Systems

Hypersen's HPS-LCF1000 is a 3D line confocal sensor that is suitable for the inspection of transparent, mirrored, and highly reflective materials. It is designed to record detailed raw data and generate various forms of 2D/3D graphs, making it an ideal tool for industrial precision measurement and scientific research.

With 2048 points per profile and 0.1μm Z-axis repeatability, the HPS-LCF1000 offers ultra-high-speed scanning of up to 35000 lines/sec. It also provides a complete SDK and one-stop software support service for seamless integration with other systems.

This sensor has a field of view of 6mm and a measurement range of 3mm, with an X-resolution of 2.9μm. It has a stand-off distance of 16mm and can handle a maximum surface slope on a mirror of ±20.5 degrees. The dimensions of the sensor are 449.3397106mm, and it weighs 19kg.

The HPS-LCF1000 is built with an IP55 ingress protection level (EN 60529) and requires a power supply of 24 VDC, 2A. It offers PC connectivity through 40G optical fiber and has digital input with optocoupler input and output.

Overall, the Hypersen HPS-LCF1000 is an excellent tool for the 3D inspection of transparent, mirrored, and highly reflective materials, with its high-speed scanning, precision, and software support service.

Working distance 3000 mm
Image Type
  • Color
  • Hyperspectral
  • Monochrome
  • Multispectral
  • MWIR
  • Near-infrared
  • SWIR
Application
  • Agriculture
  • Cleaning and maintenance
  • Delivery
  • Material handling
  • Picking and Packing
  • Security and surveillance
  • Transportation
Industry
  • Agriculture
  • Healthcare
  • Logistics
  • Manufacturing
  • Mining
  • Retail
  • Warehousing

HPS-LCF1000 Alternatives

See all 159 3D Vision Systems
Hypersen HPS-LCX1000
Monochrome | Working distance 500mm
No reviews yet.
Hypersen HPS-LCX1000 is designed for high-precision 3D inspection of transparent, mirrored, and highly reflective materials, such as glass and metals. The device can record detailed raw data and generate various forms of 2D/3D graphs. With a field of view of 2.3mm and a measurement range of 1.4mm, it provides high-resolution images with X-resolution of 1.1μm and 0.1μm Z-axis repeatability.The device features ultra-high-speed scanning of 35000 lines/sec, allowing for fast and efficient inspections. It has a number of data points/X of 2048 and a stand-off distance of 9.3mm. The device can scan a full measurement range of 2,048 points at a rate of 3,100Hz. The device's maximum surface slope on a mirror is ±45 degrees, making it suitable for a wide range of applications.Hypersen HPS-LCX1000 comes with a complete SDK and one-stop software support service, making it easy to integrate into existing systems. The device is ideal for use in industrial precision measurement and scientific research, where accuracy and efficiency are critical.With its IP55 ingress protection level, Hypersen HPS-LCX1000 is rugged and durable, suitable for use in challenging environments. The device has a compact design, with dimensions of 315454104mm and a weight of 13kg, making it easy to transport and install. The device is powered by 24 VDC, 2A and has PC connectivity via a 40G fiber optic connection. It also features digital input with optocoupler input and output.
Hypersen HPS-LCF2000
